Duct Flange Forming Machines

HVAC Duct Making Flange Making Rolling Machine



Flange machine can be divided into three types according to the working requirements: single type TDF-12 and TDF-15, duplex type SBT-12.

Single type machine like TDF-12 and TDF-15 can form flange edge at one side and crispening edge at the other side; duplex type like SBT-12 can form flange edge at both sides simultaneously to improve efficiency and save time.
Additionaly duplex type can add flange edge or crispening edge outside at either side. Our company would specially introduce high-strength rolling reels made of GCr 15, a kind of steel which prolongs the machine life by more than 5 times and outputs stainless steel flange.













































Packing & Delivery





Certificate





FAQ



1. Who are we?
We are based in Wuxi which nearby Shanghai, China, start from 2005,sell to Southern Europe(30.00%),North America(20.00%),Southeast Asia(50.00%). There are total about 51-100 people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final Inspection before shipment.

3. What can you buy from us?
Auto duct line, Laser Cutting Machine,Shear machine,Punch machine,Spiral tubeformer, ovalizer,etc.

4. Why should you buy from us not from other suppliers?
1. We have more than 18 years of design and development experience.

2. We are passionate about developing innovative and sustainable solutions.

3. Harting has nearly 100 patents of innovation, utility and appearance.

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,Express Delivery.
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF.
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union.
Language Spoken:null.

Technical Data



Type	SBTDF-12	SBTDF-15
Thickness	0.5-1.2 mm	0.8-1.5 mm
Roller Shape
Height of Flange	33±0.5 mm	33±0.5 mm
Power	2.2 kw	3 kw
Weight	760 kg	910 kg
Dimension	2540×720×910 mm	2750×750×960 mm
