Electrical-Driven Shear Machine

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Motor-Driver Shear Machine

Description

SBKJ shearing machine has simple structure, convenient operation, beautiful design, beautiful appearance and low energy consumption. Mechanical scissors adopt anti-key structure and open gear clutch transmission. More advanced electric operation (foot switch, manual switch) has low operating noise and is convenient for maintenance. It is widely used in metallurgy, light industry, machinery, hardware, electrical appliances, electronics, auto repair, metal processing and other sheet metal processing industries.

Offering you a complete choice of products which include Spiral Duct Forming Machine, Round Duct Making Machine, Auto Duct Production Line, Rectangular Duct Making Machine etc.

This is a force worked Sheet Metal Shearing Machine including all steel body strong development for precision and constancy. The crankshaft keeps running in weapon metal shrubs and flies wheel shaft keeps running in a bad position free operation. Besides, our offered machine is fastidiously tried by our merchants' on unmistakable parameters, with a specific end goal to convey an impeccable extent at our customer's end.

Technical Data

Type	SBQ11-2×1300	SBQ11-3×1300	SBQ11-3×1500	SBQ11-4×2000
Thickness	2 mm	3 mm	3 mm	4 mm
Width	1300 mm	1300 mm	1500 mm	2000 mm
Cutting Angle	2°25′	2°25′	2°25′	1°30′
Stroke No	20	20	20	20
Area	350 mm	350 mm	350 mm	500 mm
Power	3 kw	3 kw	3 kw	5.5 kw
Weight	794 kg	1150 kg	1800 kg	2300 kg
Dimension	1920×960×1120 mm	1990×1010×1120 mm	2515×1500×1300 mm	2650×880×1140 mm
